SGQ-150D VHF Filter

  • SGQ-150D  VHF   Filter
  • SGQ-150D  VHF   Filter
  • SGQ-150D  VHF   Filter
  • SGQ-150D  VHF   Filter
Model No.︰-
Brand Name︰JIESAI
Country of Origin︰China
Unit Price︰US $ 55 / pcs
Minimum Order︰1 pcs
Share on:

 Total 15 Related Items
Prev34567Next

Product Description
specification
Type SGQ-150D
Frequency Range 137-180MHz
 VSWR ≤1.40
Bandwidth(KHz) ±100 ±200 ±100
Frequency Spacing(MHz) >6-15 >5-6 >3.8-5
Insertion Loss ≤1.5dB ≤1.2dB ≤1.5dB
Isolation ≥75dB
Maximum Input Power 50W
Normal Impedance 50Ω
Connector N-F/BNC-F
Operating Temperature -20℃ - +50℃
Weight(kg) 1.5KG
Dimensions 218×190×40(±0.5mm)
Payment Terms︰T/T,paypal
Product Image
